Description
You have FIOS installed? You want to install web camera? You are not professional and do not want to learn networking?Keep reading...
You could find all answers yourself by googling the web as I did.The research took time and efforts. There are a lot of resources available.Unfortunately all of them are scattered and I was not able to find a single one with full description of required steps. In many cases you cannot ask a question because you do not know why webcamis not working. Often it's not clear what steps and in what order to take. Many forums discuss web camera installation. Usually discussions are very specificto a problematic step and sometimes are misleading.Hopefully these notes will help you to install your web camera. I'm not sure that I can reproduce myself all these steps without written notes...
2.1 IP Camera Tool When the Device has been mounted properly, you can double click the icon “IP Camera Tool” and a dialog box as Figure 2.1 will pop up. Figure 2.1 Note: The software searches IP Servers automatically over LAN. There are 3 cases: 1 No IP Camera found within LAN. After about 1 minute search, the Result Field will show. 192.168.1.1:8080 free download. TCP Over HTTP Tunnel TCP Over HTTP Tunnel Free Server Provided by Fastssh.com Server: tcp.serverip.co Ports: 80, 8080. Note: The steps below assume you already have your IP camera installed and connected to a router with Internet access. HTTP://192.168.1.101 represents the IP address of the camera being accessed. Find your camera’s IP address. If you don’t know its IP address, click here. Open a web browser and type the IP address. Login Page - Access the login page by typing 192.168.1.10 into your browser and pressing enter. Links Don't Work - If they time out, or take more than a few seconds to load, you must have the wrong IP address. Try one of these IP addresses: 192.168.1.1 192.168.0.1 192.168.2.1 192.168.1.254 192.168.
Your router
I have a Verizon FIOS with MI424WR Verizon router. The instructions below maybe still useful if you have a different router.The Verizon MI424WR router is manufactured by Actiontec.You could find a lot of information about Actiontec MI424WR router.The difference between Actiontec MI424WR and Verizon MI424WR routers is in logo and minor Verizon specific updates. Use Actiontec keyword surfing the web for details and HowTos about your router.
Web camera
There are many different wireless web cameras on the market. Search the web for cameras manufactured by Linksys, TRENDnet, Panasonic, D-Link.
I bought Linksys WVC54GCA Wireless-G Internet Home Monitoring camera. The price is about $100. You could consider buying more expensive camera with tilt and pan, night vision, enhanced sound and other features. Do not buy obsolete Linksys WVC54GC or WVC54G!
You may already read bad reviews about Linksys WVC54GCA. The camera has both strong and weak sides.After you manage to set it up the camera is not so bad for the price.Picture is good. Sound is awful. Price is acceptable. Do not believe manuals which warns that video stream could be viewed only in IEwith ActiveX installed. The stream is perfectly viewed without any plugins and installations in Firefox v2 / v3 and IE v7. I did not check other web browsers. I expect all contemporary browsers to display camera video stream without problem.
The instructions below maybe still useful if you have a different camera.
See also
Linksys Wireless-G Internet Home Monitoring Camera Review
Step 1. Obtain dynamic DNS
Your internet provider assigns your router some unique IP address, e.g. 12.34.56.78, which is used to access your router and your network from the web.For example, when you open Google web page your browser sends request to Google'sweb site with your IP address as a destination for the Google to send requested page.
Usually your router IP address is assigned dynamically. This means that the IP address might be changed at any time. The IP address as numbers are OK for browsers but not very convenient for a user to access your network.Moreover, these numbers might change at any time. The alternative to access your network via IP address is obtaining dynamic DNS.
Other options which are not discussed here includes: you have a registered web address or you pay extra for a static IP address.
Dynamic DNS allows you to access your local network from the web using web address like myname.dyndns.org which is mapped to your IP address. The mapping is changed each time your IP address is changed.You are still using the same myname.dyndns.org without knowingabout actual IP address change.
Many companies provide dynamic DNS service. Usually you have to pay for this service. One rare exception is DynDNSwhich provides free service for a single IP address. This is exactly what you need.Go to DynDNS website and create an account. Then add new host in your accountwith your name,e.g. http://myname.dyndns.org. Download and install DynDNS updater on one computer in your local network.This updater will notify DynDNS about your IP address change.Your responsibility is to have this computer with installed DNS updater running at least periodically. This is required for DynDNS client service installed on your machineto force updater to send notifications to DynDNS server even if your IP is not updated at least once in 28 days interval to keep your DynDNS account active.
See also
Dynamic DNS Readme
Dynamic DNS How-To
DynDNS Updater Installation Guide
Why can't I connect to my server?
An Alternative to Sololink and Set-up problems
Using Dynamic DNS and Remote Desktop with Fios
Step 2. Remote router access
This step is not required for web camera operation, however it's veryconvenient to remotely access your router and view or modifysome settings on it.
Your router admin pages are available from local network at address http://192.168.1.1.With new DynDNS account you created in a previous step you will be able to access your router admin pages from external network.
Open page Remote Administration and update the following entry:Access your router admin pages at addresshttps://myname.dyndns.org to make surethat remote router administration is enabled and DynDNS is working properly.
Step 3. Remote desktop access
This step is not required for web camera operation, however it's veryconvenient to remotely access machine in your local network to start / stop applications and view / modify settings.
Go to the router admin web site and open the page Port Forwarding. Click Add at the bottom of the page and enter the following on the Add Port Forwarding Rule page:Note, the name of networked computer is a machine in your network you want to access remotely.
192 168 1 101 8080 Ip Webcam Setup
Test remote desktop functionality on Windows: go to the Start / Programs / Accessories / Communications / Remote Desktop Connection. In the popup window enter myname/dyndns.organd login remotely to machine in your network.
See also
Port Forwarding for the Actiontec MI-424-WR
Step 4. Update router dynamic DNS
This step is described in details in the article Using Dynamic DNS and Remote Desktop with Fios.I'm not convinced that this step is required and more tests are required.The problem with Verizon MI424WR router testing is that it does not allow easily to remove entries made on the Dynamic DNS page.
Go to the router admin web site and open the page Dynamic DNS. Update the following entries:
See also
Using Dynamic DNS and Remote Desktop with Fios
Step 5. Update router DHCP IP addresses range
Web camera must have a static IP address within your network while the default setting on the router does not leave range for static IP addresses.
Go to the router admin web site and open the page DHCP Settings for Network (Home/Office). Update the following entries (I assume that you have less then 100 computers in your network):
Step 6. Set camera static IP address
Initially the camera is connected to the network with a network cable.The camera IP address is setup automatically with the first available on yourlocal network IP address. For example, you have two computers in your local network.The IP address 192.168.1.1 is reserved for the router.IP addresses of networked computers are 192.168.1.2 and 192.168.1.3. The web camera will be assignedIP address 192.168.1.4 as a first available address. You could check this IP address using web camera utility or learn IP addressfrom the router main page in the column My Network.
Go to the web camera admin utility setup pagehttp://192.168.1.4 and select in the left pane option Basic.Scroll to Network Settings section in the right pane and update the following entries:Note, the last number 101 in the web camera IP Address is outside of dynamic IP addresses taken by router 2..100 DHCP range defined in the previous step.
See also
Fios & Linksys Internet camera - setup questions
Unplug network cable from the camera and plug it back. Reboot camera.Test http://192.168.1.101 IP addressin the web browser. You should be able to load the web camera admin utility setup page from new static IP address 192.168.1.101.
Step 7. Learn router wireless security settings
This was the most painful step for me, 'thanks' to conflicting definitions inrouter and web camera.
Go to the router admin web site and open the page Basic Security Settings. Write down the following information from this page (example below for 64/40 bit WEP Key):The trick is a WEP Key Code which you should know both as ASCII and Hex.The ASCII Key Code value is a plain text which is usually entered when you connect wireless devices to your network. Web camera requires Key Code value as Hex. Let's say your current Key Code is hello typed as ASCII.Change ASCII to Hex and write down WEP Key Code 68656c6c6f as Hex.Do not click Apply on the bottom of the screen. Navigate away from this page because you already learned what you need.
Step 8. Set camera wireless access
Go to the web camera http://192.168.1.101admin utility setup page. Select in the left pane entry Basic and scroll to Wireless Settings section in the right pane. Update the following entries:
Click the button Edit Security Settings and update the following entries:Looks obvious, isn't it?
Test camera wireless connection: unplug camera from the network,reboot it and open http://192.168.1.101admin utility. The page displayed is a proof of successful web camera connection to the network.
Step 9. Add router protocol for web camera
192 168 1 101 8080 Ip Webcam Download
Go to the router admin web site and open the page Protocols. Click Add at the bottom of the page and enter the following on the Edit Service page:Click Apply. The router port 1024 will be associated withthe new web camera. You could use any port except standard ports. This new protocol moves connection to the new web camera away from default port 80 which is blocked by Verizon.
Step 10. Update router port forwarding
Go to the router admin web site and open the page Port Forwarding. Click Add at the bottom of the page and enter the following on the Add Port Forwarding Rule page:Note, the specified address 192.168.1.101 is taken from Step 6, see above.
Ip 192.168.1.101
See also
Port Forwarding for the Actiontec MI-424-WR
Step 11. Camera video
The camera is able to stream video in MJPEG and MPEG-4 formats. The MJPEG format is supported by many browsers. The following simple web page displays your video (no sound):
Streaming video with sound or in MPEG-4 format requires more efforts. For example, you have options to install Linksys plugin for IE to view stream in browser or web camera utility to view stream in the desktop application.
See also
How To Embed a Linksys Wireless-G Internet Home Monitoring Camera
